Trainings & Short Courses

Following short courses and trainings are conducted at Department of Avionics Engineering:

  • -Synthetic Aperture Radar Theory and Application

  • -LabVIEW Core I & II

  • -LabVIEW FPGA

  • -MEMS for Aerospace Application

  • -Real Time DSP for Communications

  • -Vx Works & FPGA Digital Design with LabVIEW

  • -Modelling & Simulation of Aircraft Dynamics

  • -Avionics System Integration

  • -Navigation Systems

  • -Basics of Energetic Materials

  • -Advanced Energetic Materials

  • -Laser Optics and laser Proximity Fuses

  • -Explosive Formulation and Fillings

  • -Detection and Analysis of Explosives

Salient Projects

Department of Avionics Engineering also works on the research projects. These projects are provided by different Government and private organizations. A salient list projects at Department of Avionics Engineering is as under

Tele-Medicine with LabVIEW

Rugged Telemedicine system for Rural Health Services is an interesting project. Air University and Planet NI are collaborating on the provisioning of rural health services through automated patient encounters by an embedded Patient Data Concentrator that is linked to OpenMRS (medical record system).

No Image No Image

Follow-on Receiver & Spectrum Analysis COMJAM Applications

This system is an extension of an MS thesis conducted at Avionics Department. Capable of analyzing radio sets with 4000hops per second with the accuracy up to 1Khz and lower hop rates with an accuracy of <10Hz. Detection time is less than 98 Microseconds.

No Image

Automated Spring Mass Damper System

  • -Replaces Manual Mass spring damper

  • -Records and measures various parameters using sensors

  • -Print all these parameters on single report and the end of experiment

No Image
No Image

Data Logger for DA-20

Data logger has been installed in DA-20 for thermal analysis of APU compartment. Installation been has been Completed on the aircraft with one Engineering display console and one Pilot console in the cockpit, the system gives a clear trend of the APU status.

No Image
No Image

Thermal Profiling of F-7 Aircraft Avionics Bay

A Data Logger was deployed on a supersonic aircraft and flew for one year in all-weather profiles. The huge correlated datasets captured were analyzed using state-of-the-art data-mining tools at Air University. The analysis report of Air University was accepted and trials for the recommended modification to control the avionics bay temperature, are underway.

No Image

Helicopter Track & Balance

Helicopter track and balance kit was developed by the Department of Avionics Engineering for Army Aviation. Kit has been tested by Aviation Squadron in Quetta and is undergoing further testing at 503 EME workshop Dhamial

No Image
No Image

Vibration Monitoring of Lycoming 360E

This system measures the vibration of the engine under test. Allows user to extract valuable health information and fault diagnosis of the engine using joint time frequency analysis

No Image

Data Link Processor

In collaboration with National Instruments we are developing a next generation hybrid Embedded Avionics Platform Critical for transitioning from federated to IMA architectures

No Image

Spectral Analysis and Direction Finding System COMINT Applications

This system is capable of Analyzing and demodulating numerous modulation schemes.

No Image

Salient Thesis

Click here to view
